PLC on a Chip™
When you need the brains of a PLC embedded right into your product without writing low-level firmware, PLC on a Chip™ gives you ladder-programmable control in a single IC or module, cutting time-to-market and simplifying design.
What you gain:
Faster development: EZ LADDER® kernel—no low-level drivers required.
Plenty of I/O and speed: up to 164 digital I/O and 8 analog I/O (expandable), high-speed counters, quadrature.
Embedded comms: serial, CAN, Ethernet; Modbus, J1939, NMEA 2000.
Flexible integration: IC (SMT) or module (thru-hole) formats + dev kits.
Embedded
Comms
Faster
Development
Flexible
Integration
Ideal for: OEMs building custom electronics that need a programmable controller baked in (keypads/LCDs, communications, and expansion buses supported).
P-Series PLC on a Chip
The P-Series combines powerful peripherals with industry standard I/O for a complete package that provides the advanced features required while providing an easy-to-use ladder diagram programming interface; EZ LADDER Toolkit.
Click on a model for more information. Brochures and Datasheets are downloadable within each model description.
| MODEL | Module or Integrated Circuit | Digital Inputs / Outputs / PWM | Analog Inputs / Outputs | Counters / Quadrature | CAN Port(s) | Serial Port(s) | Ethernet |
|---|
PLCHIP-P10-51220 ▼ I 106*/106*/3 8/1 2/1 2 4 X
| PLCHIP-P10-51220 ▼ | I | 106*/106*/3 | 8/1 | 2/1 | 2 | 4 | X |
|---|
Price: CONSULT FACTORY
Accessories
- 3.3V Logic Level (I/O 5V tolerant)
- Integrated Circuit (IC)
- Up to 106 Digital I/O (Input or Output), 3 PWM Capable
- Up to 8 Analog Inputs (12 bit)
- Up to 1 Analog Output (10 bit)
- 2 High Speed Counters, 1 Quadrature (A/B/Reset)
- 2 CAN Ports, J1939 Read/Write
- 4 Serial Ports, Modbus Master/Slave
- Ethernet, Modbus TCP
- SD Card Interface
- LCD Support
- 3 I2C Ports and 2 SPI Ports
- P-Series EZ LADDER Toolkit (Ladder & Structured Text)
- P-Series P10 Chip Datasheet
- P-SERIES PLCHIP Brochure
Click on a model to download the zip file.
- PLCDK-P10-01: P10 P-Series PLC on a Chip Development Kit (P10x Module)
PLCHIP-P13-51220 ▼ I 164*/164*/12 8/1 3/1 2 4 X
| PLCHIP-P13-51220 ▼ | I | 164*/164*/12 | 8/1 | 3/1 | 2 | 4 | X |
|---|
Price: CONSULT FACTORY
- 3.3V Logic Level (I/O 5V tolerant)
- Integrated Circuit (IC)
- Up to 164 Digital I/O (Input or Output), 12 PWM Capable
- Up to 8 Analog Inputs (12 bit)
- Up to 1 Analog Output (10 bit)
- 3 High Speed Counters, 1 Quadrature (A/B/Reset)
- 2 CAN Ports, J1939 Read/Write
- 4 Serial Ports, Modbus Master/Slave
- Ethernet, Modbus TCP
- SD Card Interface
- LCD Support
- 3 I2C Ports and 2 SPI Ports
- P-Series EZ LADDER Toolkit (Ladder & Structured Text)
- P13 Chip Datasheet
- P-SERIES PLCHIP Brochure
Accessories
Click on a model to download the zip file.
- PLCDK-P13-01: P10 P-Series PLC on a Chip Development Kit (P10x Module)
PLCMOD-P10-512210 ▼ M 106*/106*/3 8/1 2/1 2 4 X
| PLCMOD-P10-512210 ▼ | M | 106*/106*/3 | 8/1 | 2/1 | 2 | 4 | X |
|---|
Price: CONSULT FACTORY
- 3.3V Logic Level (I/O 5V tolerant)
- Plug-in Module
- Up to 106 Digital I/O (Input or Output), 3 PWM Capable
- Up to 8 Analog Inputs (12 bit)
- Up to 1 Analog Output (10 bit)
- 2 High Speed Counters, 1 Quadrature (A/B/Reset)
- 2 CAN Ports, J1939 Read/Write
- 4 Serial Ports, Modbus Master/Slave
- Ethernet, Modbus TCP
- Micro SD Card Socket
- LCD Support
- 3 I2C Ports and 2 SPI Ports
- P-Series EZ LADDER Toolkit (Ladder & Structured Text)
- P-Series P10 Module Datasheet
- P-SERIES PLCHIP Brochure
Accessories
Click on a model to download the zip file.
- PLCDK-P10-01: P10 P-Series PLC on a Chip Development Kit (P10x Module)
PLCMOD-P13-512210 ▼ M 164*/164*/12 8/1 3/1 2 4 X
| PLCMOD-P13-512210 ▼ | M | 164*/164*/12 | 8/1 | 3/1 | 2 | 4 | X |
|---|
Price: CONSULT FACTORY
- 3.3V Logic Level (I/O 5V tolerant)
- Plug-in Module
- Up to 164 Digital I/O (Input or Output), 12 PWM Capable
- Up to 8 Analog Inputs (12 bit)
- Up to 1 Analog Output (10 bit)
- 3 High Speed Counters, 1 Quadrature (A/B/Reset)
- 2 CAN Ports, J1939 Read/Write
- 4 Serial Ports, Modbus Master/Slave
- Ethernet, Modbus TCP
- Micro SD Card Socket
- LCD Support
- 3 I2C Ports and 2 SPI Ports
- P-Series EZ LADDER Toolkit (Ladder & Structured Text)
- P-Series P13 Module Datasheet
- P-SERIES PLCHIP Brochure
Accessories
Click on a model to download the zip file.
- PLCDK-P13-01: P10 P-Series PLC on a Chip Development Kit (P10x Module)
# = # of
M = Module / I= Integrated Circuit
* Total I/O -Multipurpose – Input or Output
M-Series PLC on a Chip
Designed to provide embedded intelligence in OEM products, the patented* PLC on a Chip® is a cost-effective programmable logic controller packaged in a single integrated circuit. All I/O and integrated functions are pre-assigned for use within the Divelbiss EZ Ladder® PC based, industrial ladder diagram software. The full featured PLC on a Chip controller and EZ Ladder combination provides for solutions that are both versatile and easy to implement.
Click on a model for more information.
| MODEL | Module or Integrated Circuit | Digital Inputs / Outputs / PWM | Analog Inputs / Outputs | Counters / Quadrature | CAN Port(s) | Serial Port(s) | Ethernet |
|---|
PLCHIP-M2-25600 ▼ I 33/33/8 8/0 2/0 1
| PLCHIP-M2-25600 ▼ | I | 33/33/8 | 8/0 | 2/0 | 1 |
|---|
Price: CONSULT FACTORY
- 5V Logic Level
- Integrated Circuit (IC)
- Up to 33 Digital Inputs
- Up to 33 Digital Outputs (8 PWM Capable)
- Up to 8 Analog Inputs (10 bit)
- 2 High Speed Counters
- 1 Serial Port, Modbus Slave
- LCD Support
- 2 SPI Ports
- M-Series EZ LADDER Toolkit (Ladder)
PLCHIP-M2-25620 ▼ I 33/33/8 8/0 2/0 3 1
| PLCHIP-M2-25620 ▼ | I | 33/33/8 | 8/0 | 2/0 | 3 | 1 |
|---|
Price: CONSULT FACTORY
- 5V Logic Level
- Integrated Circuit (IC)
- Up to 33 Digital Inputs
- Up to 33 Digital Outputs (8 PWM Capable)
- Up to 8 Analog Inputs (10 bit)
- Up to 3 CAN Ports, J1939 Read Only
- 2 High Speed Counters
- 1 Serial Port, Modbus Slave
- LCD Support
- 2 SPI Ports
- M-Series EZ LADDER Toolkit (Ladder)
PLCHIP-M2-12800 ▼ I 33/33/0 8/0 2/0
| PLCHIP-M2-12800 ▼ | I | 33/33/0 | 8/0 | 2/0 |
|---|
Price: CONSULT FACTORY
- 5V Logic Level
- Integrated Circuit (IC)
- Up to 33 Digital Inputs
- Up to 33 Digital Outputs
- Up to 8 Analog Inputs (10 bit)
- 2 High Speed Counters
- LCD Support
- 2 SPI Ports
- M-Series EZ LADDER Toolkit (Ladder)
PLCMOD-M2-256210 ▼ M 33/33/8 8/0 2/0 3 1
| PLCMOD-M2-256210 ▼ | M | 33/33/8 | 8/0 | 2/0 | 3 | 1 |
|---|
- 5V Logic Level
- Plug-in Module
- Up to 33 Digital Inputs
- Up to 33 Digital Outputs (8 PWM Capable)
- Up to 8 Analog Inputs (10 bit)
- Up to 3 CAN Ports, J1939 Read Only
- 2 High Speed Counters
- 1 Serial Port, Modbus Slave
- LCD Support
- 2 SPI Ports
- Real Time Clock
- M-Series EZ LADDER Toolkit (Ladder)
PLCMOD-M2-256000 ▼ M 33/33/8 8/0 2/0 1
| PLCMOD-M2-256000 ▼ | M | 33/33/8 | 8/0 | 2/0 | 1 |
|---|
- 5V Logic Level
- Plug-in Module
- Up to 33 Digital Inputs
- Up to 33 Digital Outputs (8 PWM Capable)
- Up to 8 Analog Inputs (10 bit)
- 2 High Speed Counters
- 1 Serial Port, Modbus Slave
- LCD Support
- 2 SPI Ports
- M-Series EZ LADDER Toolkit (Ladder)
PLCMOD-M2-128000 ▼ M 33/33/0 8/0 2/0
| PLCMOD-M2-128000 ▼ | M | 33/33/0 | 8/0 | 2/0 |
|---|
- 5V Logic Level
- Plug-in Module
- Up to 33 Digital Inputs
- Up to 33 Digital Outputs (8 PWM Capable)
- Up to 8 Analog Inputs (10 bit)
- 2 High Speed Counters
- LCD Support
- 2 SPI Ports
- M-Series EZ LADDER Toolkit (Ladder)
# = # of
M = Module / I= Integrated Circuit
* Total I/O -Multipurpose – Input or Output
