Open Board Products
When you’re mounting in a control panel and want maximum features at a compelling cost, open-board PLCs deliver. You get flexible I/O, a range of comms (Ethernet, cellular, CAN/J1939, Modbus, Wi-Fi), and expansion options, all in formats designed for standoff or DIN-rail mounting.
What you gain:
Right-sized hardware: multiple footprints and temperature ratings (0–60°C or -40–80°C).
Configurable I/O: digital, analog, relays, PWM, high-speed counting.
Human interface options: keypad/display and remote HMI where needed.
IoT-enabled, local webserver and EZ LADDER® programming.
Mobile
Machinery
Outdoor/Field
Equipment
Harsh Industrial
Zones
Ideal for: in-panel control, OEM cost-sensitive builds, projects needing configurable I/O and scalable comms without a sealed enclosure.
| MODEL | Digital Inputs/Outputs | Counter Inputs | Analog Input/Outputs | CAN Port(s) | Serial Port(s) | Ethernet / Wi-Fi |
|---|
HEC-GW-X-X X '1/1 2
| HEC-GW-X-X | X | '1/1 | 2 |
|---|
- 1 Digial Input (High Speed Counter) / 1 Digital Output
- 2 Analog Inputs, 0-5VDC/0-10VDC/0-20mADC
- 1 CAN Port – J1939 Read/Write, NMEA 2000
- 2 Serial Ports – RS232 (Modbus Master/Slave)
HEC-GW-X-W X '1/1 2 X
| HEC-GW-X-W | X | '1/1 | 2 | X |
|---|
- 1 Digial Input (High Speed Counter) / 1 Digital Output
- 2 Analog Inputs, 0-5VDC/0-10VDC/0-20mADC
- 1 CAN Port – J1939 Read/Write, NMEA 2000
- 2 Serial Ports – RS232 (Modbus Master/Slave)
- Wi-Fi (Modbus TCP)
HEC-GW-C-X X '1/1 2 X
| HEC-GW-C-X | X | '1/1 | 2 | X |
|---|
- 1 Digial Input (High Speed Counter) / 1 Digital Output
- 2 Analog Inputs, 0-5VDC/0-10VDC/0-20mADC
- 1 CAN Port – J1939 Read/Write, NMEA 2000
- 2 Serial Ports – RS232 (Modbus Master/Slave)
- Cellular Data Modem
HEC-GW-C-W X '1/1 2 X X
| HEC-GW-C-W | X | '1/1 | 2 | X | X |
|---|
- 1 Digial Input (High Speed Counter) / 1 Digital Output
- 2 Analog Inputs, 0-5VDC/0-10VDC/0-20mADC
- 1 CAN Port – J1939 Read/Write, NMEA 2000
- 2 Serial Ports – RS232 (Modbus Master/Slave)
- Wi-Fi (Modbus TCP)
- Cellular Data Modem
VCG-E-X-X X
| VCG-E-X-X | X |
|---|
- 2 CAN Ports : 1 -J1939 Read/Write, 1-NMEA Complaint (NMEA 2000)
- 2 Serial Ports – RS232/RS485 (Modbus Master/Slave)
- Ethernet Port – RJ45 (Modbus TCP)
- 5 Programmable LEDs
VCG-E-X-G X
| VCG-E-X-G | X |
|---|
- 2 CAN Ports : 1 -J1939 Read/Write, 1-NMEA Complaint (NMEA 2000)
- 2 Serial Ports – RS232/RS485 (Modbus Master/Slave)
- Ethernet Port – RJ45 (Modbus TCP)
- GPS Location
- 5 Programmable LEDs
VCG-E-C-X X X
| VCG-E-C-X | X | X |
|---|
- 2 CAN Ports : 1 -J1939 Read/Write, 1-NMEA Complaint (NMEA 2000)
- 2 Serial Ports – RS232/RS485 (Modbus Master/Slave)
- Ethernet Port – RJ45 (Modbus TCP)
- Cellular Data Modem
- 5 Programmable LEDs
VCG-E-C-G X X
| VCG-E-C-G | X | X |
|---|
- 2 CAN Ports : 1 -J1939 Read/Write, 1-NMEA Complaint (NMEA 2000)
- 2 Serial Ports – RS232/RS485 (Modbus Master/Slave)
- Ethernet Port – RJ45 (Modbus TCP)
- Cellular Data Modem
- GPS Location
- 5 Programmable LEDs
VCG-W-X-X X
| VCG-W-X-X | X |
|---|
- 2 CAN Ports : 1 -J1939 Read/Write, 1-NMEA Complaint (NMEA 2000)
- 2 Serial Ports – RS232/RS485 (Modbus Master/Slave)
- Wi-Fi (Modbus TCP)
- 5 Programmable LEDs
VCG-W-X-G X
| VCG-W-X-G | X |
|---|
- 2 CAN Ports : 1 -J1939 Read/Write, 1-NMEA Complaint (NMEA 2000)
- 2 Serial Ports – RS232/RS485 (Modbus Master/Slave)
- Wi-Fi (Modbus TCP)
- GPS Location
- 5 Programmable LEDs
VCG-W-C-X X X
| VCG-W-C-X | X | X |
|---|
- 2 CAN Ports : 1 -J1939 Read/Write, 1-NMEA Complaint (NMEA 2000)
- 2 Serial Ports – RS232/RS485 (Modbus Master/Slave)
- Wi-Fi (Modbus TCP)
- Cellular Data Modem
- 5 Programmable LEDs
VCG-W-C-G X X
| VCG-W-C-G | X | X |
|---|
- 2 CAN Ports : 1 -J1939 Read/Write, 1-NMEA Compliant (NMEA 2000)
- 2 Serial Ports – RS232/RS485 (Modbus Master/Slave)
- Wi-Fi (Modbus TCP)
- Cellular Data Modem
- GPS Location
- 5 Programmable LEDs
